Item number: ST-500WRS
| 5" Wireless Monitor Specification | |
| Screen | 5 inch IPS screen |
| Screen ratio | 16:9 |
| Resolution | 800*R.G.B*480 |
| Backlight | LED, 500 cd/m2 |
| Viewing angle | Hor. L(85) R(85) Ver. UP(85) DOWN(85) |
| Working temperature | -20~+70 degree |
| Working humidity | 85%RH |
| Storage temperature | -30~+80 degree |
| Power supply | DC 12-24V |
| Delay time | 120mS |
| Electric current | TYPE:300mA, Max.380mA |
| Power consumption | ＜5W |
| AV input | Up to link with 1 pcs wireless camera |
| Parking guide line | ON / OFF switchable |
| Operating frequency range | 2400 ~ 2483.5MHz |
| System | PAL/NTSC automatically |
| Transmission bandwidth | 3Mbps |
| Receiving sensitivity | '-88dBm@4MHZ |
| Spread spectrum mode | Frequency hopping |
| Wireless transmission distance | 300M (open area) |
| Application | Suitable for variouse car installation( Car length≤15M) |
| Accessories | wireless camera, 5DB antenna, 3M antenna extension cable, hexagon wrench, sun shield and, user manual |
| Wireless Camera Specification | |
| Image sensor | CMOS 1/2.7'' |
| Pixel | 1920×1080 pixels |
| Operating frequency range | 2400-2483.5MHZ |
| Transmission distance | 300M (open area) |
| System | PAL/NTSC automatically |
| Audio | Opptional |
| Transmission bandwidth | 8MHz BER<1E-3 |
| Image | Mirror image |
| Guide line | Support (system default) |
| Work temperature | -20~+70 ºC 85%RH MAX |
| Storage temperature | -30~+85 ºC 95%RH MAX |
| SNR | 46.5dB |
| Waterproof level | IP69K/IP68(with microphone) |
| Viewing Angle | 140°(Diagona) 120° (horizontal) |
| Transmitting sensitivity | -89 dBm |
| Shell material | Black aluminium alloy |
