Starlight Sony AHD 1080P Rear Camera

PRODUCT INTRODUCTION

Item number: ST-C05A-S

Starlight Sony AHD 1080p Rear Camera

Products Overview:

Enhance your vehicle’s safety with the heavy-duty Starlight Sony AHD 1080P rear camera,engineered for crystal-clear night vision and rugged performance,featuring a 1/2.8" Sony Starvis IMX307 or Starvis 2 IMX662 sensor,this camera delivers full HD resolution and exceptional low-light clarity—perfect for reversing or monitoring in dark or challenging environments.

Key Features:

Full HD 1080P Resolution: Sharp imaging with 2MP clarity
Starlight Night Vision: Superior low-light performance without IR glare
IP69K Waterproof & Dustproof: Built for rain, mud, and extreme conditions
Zinc alloy Housing: Durable and heat-resistant casing
Adjustable Mounting: 90° tilt for optimal positioning
Wire harness: M12 4-pin avation connector, double-shielded pure copper wire
WDR function: Wide Dynamic Range
Approvals & Certification: E-Mark, CE

Product Specs:

Category	Parameter
Image Sensor	1/2.8" Sony Starvis IMX307 or Sony Starvis2 IMX662
Resolution	AHD 1080P
Effective Pixels	1920(H) x 1080(V)
WDR function	Optional
TV System	PAL/NTSC
Viewing angle	120 Degree
Lens	2.8MM
Power supply	DC 12V
Waterproof Level	IP69K
Power Consumption	0.8W±10％
Maximum current	80mA
Minimum Illumination	Color 0.0011LUX/F1.2
Video Output	1.0 Vp-p/75 Ohm
Connector	4pin aviation
Operating Temperature	-30℃～70℃, RH 95% MAX

Product Applications:

Perfect for Trailer,Trucks,Commercial vehicles,RVs etc, ensuring safe and reliable reversing in all light conditions

Standtop's Starlight Sony AHD 1080p camera works on Trucks, it was provided by our overseas customer by July,2025, the below image have been compressed:
