1080P AHD Heavy Duty Truck Camera | IP69K Waterproof & Vibration Proof

PRODUCT INTRODUCTION

Item number: ST-C05A

Heavy-Duty 1080P AHD Truck Camera

Key Features:

Full HD 1080P Resolution: 1920*1080, 2MP
Wide-Angle Lens: 120° field of view reduces blind spots
Night Vision: 18pcs Infrared LEDs ensure visibility in total darkness
IP69K Waterproof & Dustproof: Built to withstand rain, mud, and pressure washing
Shockproof Design: Vibration-resistant for rough terrain and heavy machinery
Approvals & Certification: E-Mark, CE

Product Specs:

Category	Parameter
Image Sensor	1/2.9" CMOS Sensor
Resolution	AHD 1080p
Effective Pixels	1920(H) x 1080(V)
TV System	PAL/NTSC
Viewing angle	120 Degree
Power supply	DC 12V , 24V optional
Waterproof Level	IP69K
IR lights	18Pcs
Image	Mirror or Normal optional
Power Consumption	＜3W
Maximum current	＜250mA
Minimum Illumination	0.1 Lux (day), 0 Lux (with IR)
Video Output	1.0 Vp-p/75 Ohm
IR cut	Yes
Connector	4pin aviation
Operating Temperature	-30℃～70℃, RH 95% MAX

Product Applications:

Mining & Heavy Transport: Survives the dust, rock impact, and harsh vibration of quarrying.
Fleet Logistics: Durable enough for daily wash-downs and high-mileage road service.
Construction & Agriculture: Resistant to chemical exposure, fertilizers, and environmental debris.

FAQ:

Q: Is this camera waterproof?

A: Yes, it is rated IP69K. This is the highest protection rating available, allowing the camera to be cleaned with high-pressure steam washers without risk of seal failure or lens fogging.

Q: Does it work with any monitor?

A: It outputs an AHD 1080P signal. It requires a monitor or MDVR that supports AHD input. It is the perfect companion for our 7" and 10.1" high-definition monitors.

Q: Can this handle 24V power systems?

A: The standard camera is typically powered via the monitor or MDVR (12V). For direct-to-battery 24V installations, we offer customized internal power management to handle industrial voltage spikes.

Q: How does it perform in winter?

A: It with a tested operating range of -30°C to +70°C.
