PRODUCT INTRODUCTION

Item number: ST-CMOS-669

  • CVBS Car reverse camera
  • CVBS Car reverse camera
  • CVBS Car reverse camera
  • CVBS Car reverse camera
  • CVBS Car reverse camera
  • CVBS Car reverse camera
  • CVBS Car reverse camera
  • CVBS Car reverse camera
Inquiry Now
CVBS Car reverse camera

Specification:

 Image Sensor  PC7080 CMOS Sensor
 Resolution  600TVL
 TV System  PAL/NTSC
 Viewing angle  170 Degree
 Power supply  DC 12V
 Waterproof Level  IP68
 Parking Line  On/off  Optional
 Image   Mirror on/off optional
 Shockproof level   4G
 S/N ratio   Better than 60dB
 Minimum Illumination  0.1 Lux
 Video Output  1.0 Vp-p/75 Ohm
 Connector  RCA
 Operating Temperature   -20℃~70℃, RH 95% MAX
 Storage Temperature  -30℃~80℃, RH 95% MAX

CE-mark: EN 55022:2010+AC:2011 ; EN 55024:2010 ; EN61000-3-2:2006+A1:2009+A2:2009 ; EN 61000-3-3:2013

E-Mark: E24 10R06 01 3879 00
